立式多功能淬火真空爐
主要用于合金鋼、合金結構鋼、工模具鋼、彈簧鋼、軸承鋼、不銹鋼、精密合金鋼等材料的光亮淬火、調質及磁性材料的燒結，光亮退火及真空釬焊，該設備適用于細長軸，薄壁長件，大型超重件
分享商品：
銷售電話：15318905266
立式多功能淬火真空爐
產品名稱：立式多功能淬火真空爐
Name: Vertical Multifunctional Quenching Vacuum Furnace
規格：見技術參數 /Specification: Refer to technical parameters
用途：主要用于合金鋼、合金結構鋼、工模具鋼、彈簧鋼、軸承鋼、不銹鋼、精密合金鋼等材料的光亮淬火、調質及磁性材料的燒結，光亮退火及真空釬焊，該設備適用于細長軸，薄壁長件，大型超重件
Application: It is mainly used for bright quenching, quenching and tempering of alloy steel, alloy structural steel, work die steel, spring steel, bearing steel, stainless steel, precision alloy steel and other materials. It is suitable for slender shaft, thin-wall long piece and large-scale overweight part.。
特點/Characteristics:
1.加熱元件沿加熱室圓周360度均勻布置，溫度均勻性達±
The heating element is evenly arranged along the circle of the heating chamber at 360 degrees, and the temperature uniformity is up to ±
2. 加熱室與淬火室分開，可選擇性淬火（油淬/氣淬/水淬）
The heating chamber is separated from the quenching chamber and can be selectively quenched (oil quenching,/gas quenching/water quenching).。
3.淬火攪拌機構變頻調速且帶有導流裝置，冷卻均勻性好、工件變形小
The quenching mixing mechanism has variable frequency speed regulation and flow diversion device, good cooling uniformity and small deformation of the workpiece.
4.具有恒溫油淬火/等溫淬火/對流加熱/真空分壓
With constant temperature oil quenching / Isothermal quenching / convective heating / vacuum partial pressure
5.氣淬采用高效外循環風機， 冷卻速度提高80%
The high efficiency external circulation fan is used for gas quenching, and the cooling rate can be increased by 80%.。
6.全智能化工業計算機控制系統并有一套手動操作系統
Fully intelligent chemical industry computer control system and a manual operating system。
7.操作簡潔 編程工藝靈活輸入 機械動作穩定可靠
The operation is simple and the programming process is flexible, and the mechanical action is stable and reliable.
8.手動/半自動/自動 故障自動報警/顯示
Manual / semi-automatic / automatic fault automatic alarm / display
配置選擇/Configure select:
|
雙室垂直結構形式： Double chamber vertical structure form： |
整體式 Unitary |
加熱室移動式 Heating chamber mobile |
淬火槽移動式 Quenching tank mobile |
|
中間隔熱門 ：Middle septum hot： |
機械傳動 Mechanical drive |
氣動 /Pneumatic |
|
|
淬火槽攪拌方式： Quenching tank stirring mode： |
漿葉攪拌 Pulp blade stirring |
噴嘴噴射 Nozzle injection |
二者疊加 Superposition of the two |
|
石墨加熱元件與石墨氈復合屏合成結構； Synthesis structure of Graphite heating element and Graphite felt Composite screen 鉬加熱元件與金屬隔熱屏合成結構； The composite structure of Mo heating element and metal thermal insulation screen; 鎳鉻合金帶加熱元件與不銹鋼屏合成結構； Synthesis structure of Ni-Cr Alloy Strip heating element and stainless Steel screen |
|||
|
真空泵組和真空計； Vacuum pump set and vacuum gauge： |
進口 Imported |
高品質國產 High quality domestic |
|
|
真空度： Vacuum degree： |
高真空 High vacuum |
中真空 Medium vacuum |
|
|
PLC: |
西門子 Siemens |
歐姆龍 OMRON |
三菱 Mitsubishi |
|
溫控儀表 Thermostat meter： |
歐陸 EUROTHERM |
導電 Electric conduction |
|
|
熱電偶 : Thermocouple： |
S型分度號 S-type dividing number |
|
|
|
記錄儀 : Grapher : |
有紙記錄儀 Paper recorder |
無紙記錄儀 Paperless recorder |
|
|
人機界面: Human-computer interface |
模擬屏 Analog screen |
計算機觸摸屏 Computer touch screen |
|
|
電器元件 Electrical component： |
高品質國產 High quality Made in |
施耐德 Schneider |
西門子 Siemens |
產品 規格/ Specifications：
注：特殊規格要求可根據客戶要求定制
Note: Special specification requirements can be customized according to customer requirements
以下參數可根據工藝要求調整，不作為驗收依據，具體以技術方案和協議為準
The following parameters may be adjusted according to the process requirements and shall not be used as the basis for acceptance, depending on the technical scheme and agreement.
|
參數/型號 Parameter/ Model |
PJ-LY68 |
PJ-LY810 |
PJ-LY1012 |
PJ-LY1215 |
PJ-LY1518 |
|
有效熱區D×H(mm） Effective hot zone |
600×800 |
800×1000 |
1000×1200 |
1200×1500 |
1500×1800 |
|
裝載重量 （KG） Load weight |
500 |
800 |
1000 |
1200 |
2000 |
|
最高溫度 （℃） Max.temprature |
1150/1350 |
1150/1350 |
1150/1350 |
1150/1350 |
1150/1350 |
|
爐溫均勻性 （℃） Furnace temperature uniformity |
±5 |
±5 |
±5 |
±5 |
±5 |
|
真空度 （Pa） Vacuum degree |
4.0 E -1/ 6.7 E -3 |
4.0 E -1/ 6.7 E -3 |
4.0 E -1/ 6.7 E -3 |
4.0 E -1/ 6.7 E -3 |
4.0 E -1/ 6.7 E -3 |
|
壓升率 （Pa） Pressure rise rate |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.5 |
≤0.5 |
|
移送時間 Transfer time（S） |
≤37 |
≤45 |
≤55 |
≤70 |
≤83 |
